Descripción
ESPECIFICACIONES:
-
NOMINAL VOLTAGE: 12V
-
NOMINAL WATTAGE/CELL
-
15 min. discharge rate to 1.67V/cell → 35
-
10 min. discharge rate to 1.67V/cell → 44
-
5 min. discharge rate to 1.67V/cell → 68
-
-
NOMINAL CAPACITY
-
10 hour rate of 0.8A to 10.5V → 8.0Ah
-
5 hour rate of 1.5A to 10.2V → 7.5Ah
-
1 hour rate of 6.0A to 9.6V → 6.0Ah
-
-
WEIGHT (approx.): 6.24 pounds (2.83 kgs.)
-
ENERGY DENSITY (10 hr. rate): 1.70 WH/cubic inch (104 WH/liter)
-
SPECIFIC ENERGY (10 hr. rate): 15.4 WH/pound (33.9 WH/kg)
-
INTERNAL RESISTANCE OF CHARGED BATTERY: 14 milliohms (approx.)
-
MAXIMUM DISCHARGE CURRENT WITH STANDARD TERMINALS: 40 amperes
-
MAXIMUM SHORT-DURATION DISCHARGE CURRENT: 210 amperes
-
OPERATING TEMPERATURE RANGE:
-
CHARGE: 50°F to 122°F (-15°C to 50°C)
-
DISCHARGE: -40°F to 140°F (-20°C to 60°C)
-
-
CHARGE RETENTION (shelf life) at 68°F (20°C):
-
1 month → 97%
-
3 months → 91%
-
6 months → 85%
-
-
LIFE EXPECTANCY:
-
Standby use → 3 to 5 years
-
Cycle use (approx.):
-
100% depth of discharge → 250 cycles
-
50% depth of discharge → 550 cycles
-
30% depth of discharge → 1200 cycles
-
-
-
SEALED CONSTRUCTION: Operable in any position without leakage.
-
STANDARD TERMINAL: Quick Disconnect .250 or optional .187
-
HOUSING MATERIAL: ABS Resin
-
OPTIONAL: Container and cover made from Flame Retardant ABS (UL94-VO/L.O.I.>28%)
-
RECOGNIZED BY UL, File No. MH 16464
